[HYPER-CONVERGED HOMELAB CLUSTER v2.4]

15대 Barebone PC 클러스터 & Proxmox 홈랩 인프라

Zero Cloud-Lock-In | Hyper-Converged Edge Architecture | High-Availability B2B Nodes

AWS, GCP 등 퍼블릭 클라우드 종속성(Lock-In)을 완전히 탈피하고, 15대의 high-density 베어본 미니 PC와 Proxmox VE 8.4 기반 분산 오케스트레이션으로 초저비용 고가용성 기업용 에지 인프라를 실현합니다.

노드 카탈로그 탐색 TCO 절감액 계산
TOTAL MEMORY 384 GB DDR4/DDR5 ECC Non-Reg
CEPH STORAGE 24.0 TB PCIe Gen4 NVMe Mesh
NETWORK BACKBONE 2.5 Gbps Full Duplex Trunking
TOTAL CLUSTER TDP ~380 W Eco-Green Power Efficient
REAL-TIME TELEMETRY ENGINE

인프라 실시간 텔레메트리 & 아키텍처

Proxmox VE 8.4 기반 분산 하이퍼바이저와 K3s 쿠버네티스 오케스트레이션 메시

Proxmox VE 8.4

Cluster Node Manager & Hypervisor Stack

CPU Utilization 18.4%
RAM Allocation 142.8 GB / 384 GB
ACTIVE VMs: 42 HEALTHY

K3s Cluster

Kubernetes Container Orchestration Mesh

Active Pod Count 128 Pods
Control Plane Quorum 3/3 Nodes
INGRESS: 1.42 GB/s SYNCED

Cloudflare Tunnel

Zero Trust Encrypted Edge Gateway

Tunnel Latency 11.8 ms
DDoS Filter Rate 100% Secure
TUNNELS: 4 Active ENCRYPTED

Ceph Storage Pool

Distributed Block & Object Mesh

Pool Capacity 8.4 TB / 24 TB
Cluster IOPS 14,250 IOPS
REPLICAS: 3x Replication HEALTH_OK
AD_SLOT: High-CPC B2B Cloud Space
HARDWARE SPEC & CONTAINER ROLES

MVP 노드 카탈로그 (Dev 001 ~ Dev 012)

각 베어본 PC에 할당된 12개 핵심 Workload 롤 및 하드웨어 명세 (3x4 배열)

Edge AI Gateway 하드웨어 노드
DEV-001 ACTIVE

Edge AI Gateway

CPU: Intel N100 4C/4T 3.4GHz
RAM: 16GB DDR5 4800MHz
STORAGE: 512GB NVMe PCIe Gen3

Dual 2.5G LAN Edge Gateway, AI inference routing with Ollama & Nginx NPM

#Proxmox #Docker #Ollama #Nginx
K3s Control Plane 하드웨어 노드
DEV-002 ONLINE

K3s Control Plane

CPU: AMD Ryzen 5 5600G 6C/12T
RAM: 32GB DDR4 3200MHz
STORAGE: 1TB NVMe PCIe Gen4

Primary Kubernetes Control Plane 01, Etcd quorum, HA Proxy API balancer

#Proxmox #K3s #Kubernetes #etcd
PostgreSQL Cluster 하드웨어 노드
DEV-003 ONLINE

PostgreSQL Cluster

CPU: AMD Ryzen 7 5700G 8C/16T
RAM: 64GB DDR4 3200MHz
STORAGE: 2TB Enterprise NVMe

High-Availability Postgres DB cluster with Pgpool-II & Barman automated backup

#Proxmox #PostgreSQL #Pgpool #Backup
Redis Cache Mesh 하드웨어 노드
DEV-004 ONLINE

Redis Cache Mesh

CPU: Intel i5-12400 6C/12T
RAM: 32GB DDR4 3200MHz
STORAGE: 512GB NVMe PCIe Gen4

Distributed Redis Cluster for session persistence, rate limiting & pub/sub queues

#Proxmox #Redis #CacheMesh #PubSub
Vector Search Node 하드웨어 노드
DEV-005 ONLINE

Vector Search Node

CPU: AMD Ryzen 7 7700 8C/16T
RAM: 64GB DDR5 5600MHz
STORAGE: 2TB NVMe PCIe Gen4

Vector Database host running Qdrant & ChromaDB for LLM RAG semantic indexing

#Proxmox #Qdrant #ChromaDB #RAG
Webmin Admin Gateway 하드웨어 노드
DEV-006 ONLINE

Webmin Admin Gateway

CPU: Intel i3-12100 4C/8T
RAM: 16GB DDR4 3200MHz
STORAGE: 512GB NVMe PCIe Gen3

Centralized Barebone management dashboard, Webmin, Cockpit & IP KVM control

#Proxmox #Webmin #Cockpit #IP-KVM
Prometheus Monitoring 하드웨어 노드
DEV-007 ONLINE

Prometheus Monitoring

CPU: AMD Ryzen 5 5500 6C/12T
RAM: 32GB DDR4 3200MHz
STORAGE: 1TB NVMe PCIe Gen3

System metrics collector, Prometheus, Grafana dashboard & Loki log aggregation

#Proxmox #Prometheus #Grafana #Loki
CI/CD Runner 하드웨어 노드
DEV-008 ACTIVE

CI/CD Runner

CPU: AMD Ryzen 7 5700X 8C/16T
RAM: 64GB DDR4 3200MHz
STORAGE: 1TB NVMe PCIe Gen4

Self-hosted GitHub Actions runner & GitLab CI executor for automated builds

#Proxmox #Docker #GitHubActions #CI-CD
MinIO Object Storage 하드웨어 노드
DEV-009 ONLINE

MinIO Object Storage

CPU: Intel i5-13400 10C/16T
RAM: 32GB DDR5 4800MHz
STORAGE: 4TB NVMe Ceph Storage

S3-compatible high-performance object storage for media & database dumps

#Proxmox #MinIO #Ceph #S3-Storage
Zero Trust Security 하드웨어 노드
DEV-010 ONLINE

Zero Trust Security

CPU: Intel N100 4C/4T 3.4GHz
RAM: 16GB DDR5 4800MHz
STORAGE: 512GB NVMe PCIe Gen3

Cloudflare Tunnel daemon, Vaultwarden secret manager, WireGuard VPN relay

#Proxmox #Cloudflare #Vaultwarden #WireGuard
Kafka Message Broker 하드웨어 노드
DEV-011 ONLINE

Kafka Message Broker

CPU: AMD Ryzen 7 5700G 8C/16T
RAM: 64GB DDR4 3200MHz
STORAGE: 2TB NVMe PCIe Gen4

High-throughput event streaming & asynchronous queue message pipeline

#Proxmox #Kafka #Zookeeper #EventStream
OpenSearch Analytics 하드웨어 노드
DEV-012 ONLINE

OpenSearch Analytics

CPU: Intel i7-13700 16C/24T
RAM: 64GB DDR5 5600MHz
STORAGE: 2TB NVMe PCIe Gen4

Distributed log analysis, real-time search engine & security SIEM dashboard

#Proxmox #OpenSearch #Elastic #SIEM
FINANCIAL REALITY CHECK

AWS 대비 TCO(총소유비용) 절감액 계산기

동일 스펙의 퍼블릭 클라우드 인프라(AWS EC2 + Egress 네트워크) 대비 15대 Barebone 홈랩 클러스터를 운용할 때의 시뮬레이션 절감액을 계산하세요.

15 Nodes
1 Node (Small) 15 Nodes (Current) 50 Nodes (Enterprise)
2,500 GB
100 GB 2,500 GB (2.5 TB) 10,000 GB (10 TB)
산출 기준 안내:

• Public Cloud: AWS EC2 (c6i.xlarge 4vCPU/16GB) $120/노드/월 + Egress $0.09/GB

• Homelab Barebone: 노드당 소비전력 ~25W (월 전기세 약 $10/노드) + 감가상각/라인비용

ESTIMATED MONTHLY COST COMPARISON
Public Cloud (AWS): $2,025 /월
Barebone Homelab: $300 /월
NET MONTHLY SAVINGS
$1,725 USD
(약 ₩2,328,750 원 / 월)
85.2% COST REDUCTION
